Frame
Spark Carbon HMF Mainframe with Alloy 6011 SwingarmIntegrated Suspension TechnologyFlex Pivot / Adjustable head angleSyncros Cable Integration SystemBB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork
FOX 34 Float Rhythm Air Grip3-Modes / Kabolt 15x110mm axle / tapered steerer44mm offset / Reb. Adj. / Lockout / 130mm travel
Rear Shock
FOX NUDE 5T EVOL TrunnionSCOTT custom w. travel / geo adj.3 modes: Lockout-Traction Control-DescendCustom large Air volume / DPS / Reb. Adj.Travel 120-80-Lockout / T165X45mm
Remote System
SCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 Suspension modes
Rear Derailleur
Shimano XT RD-M8100 SGSShadow Plus / 12 Speed
Shifters
Shimano Deore SL-M6100-IR / Rapidfire PlusIspec EV clamp
Crankset
Shimano SLX FC-M7120-1 / Hollowtech 255mm CL / 32T
BB-Set
Shimano BB-MT500 / shell 41x92mm
Chain
Shimano Deore CN-M6100
Cassette
Shimano Deore CS-M6100-12 / 10-51 T
Brakes
Shimano Deore M6120 4 Piston Disc
Rotor
Shimano SM-RT64 CL / F&R 180mm
Handlebar
Syncros Fraser 2.0 DC Alloy 6061 D.B.mini Rise / back sweep 8° / 760mmSyncros Performance XC lock-on grips
H'stem
Syncros DC 2.0Syncros Cable Integration System0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 2.031.6mm / S & M size 125mm / L size 150mm / XL size 170mm
Seat
Syncros Tofino 2.0 RegularCRMO rails
Headset
Syncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Hub (Front)
Formula CL-811 / 15x110mm
Hub (Rear)
Formula CL-148M / 12x148mm / Micro SplineSyncros Axle w/Removable Leverwith 6mm Allen, T30 and T25 Tools
Spokes
Stainless Black 15G / 1.8mm
Rims
Syncros X-30SE / 32H / 30mmTubeless ready
Front Tire
Schwalbe Wicked Will 29x2.4" EVOSuper Race / TLE / 67EPI / Addix Speed Soft
Rear Tire
Schwalbe Wicked Will 29x2.4" EVOSuper Race / TLE / 67EPI / Addix Speed Grip
Approx weight in KG
13.5 (Tubeless setup)
Approx weight in LBS
29.76 (Tubeless setup)
Max. System Weight
128kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggag
