Specifications:
Designed For:Trail, all mountain and enduro riding
Inner Width: 30mm
Sizes Available: 27.5 and 29
Recommended Tire Dimensions: 2.3 to 2.5
Spoke Count: 28
Features:
Spoke reinforcements
Reserve uses externally reinforced spoke holes to strengthen the area where the rim sees the most force, around the spoke nipple. This provides for improved strength without adding unnecessary weight.
Redesigned rim bed makes tubeless set up easy
The 30|HD’s redesigned rim bed eases tubeless installation, with a shaped rim bed utilizing offset spoke holes that allows the tire to easily push past the bead bump to seat tubeless tires.
Asymmetrical Design (flipped front to rear)
Asymmetrical rims, like those on the 30|HD, build stiffer, stronger and more reliable wheels by improving the bracing angles and equalizing the spoke tensions between the drive and non-drive side spokes.
Tech
Hub
Industry 9Hydra
Wheelset Weight
1825g (29") | 1785g (27.5")
Wheel Type
Mountain
Internal Width
30mm
Spoke Count
28
ERD
598mm (29") | 559mm (27.5")
Asymmetric Offset
4mm
Recommended Tire Width
2.3 - 2.5 in.
Driver Options
XD or MicroSpline
Brake Options
6-Bolt or Centerlock
Depth
20mm
Endcap Options
Standard
Hub Spacing
110/148
